1. Contact : Mechanical Contact
2. Rating : DC 12V 50mA
3. Travel : 0.25±0.1m/m
4. Operating Force : 160±30gf
5. Contact Resistance : 100mΩ max.
6. Life : 100,000Cycles Min.
|
| MODEL
|
Knob(L) |
Color |
| ST 1101 |
4.3 |
BLACK |
| ST
1101A |
5.0 |
BLACK |
| ST 1101B |
9.5 |
BLACK |
| ST
1101C |
8.0 |
WHITE |
| ST 1101D |
14.0 |
BLACK |
| ST
1101E |
7.0 |
IVORY |
| ST 1102 |
4.3 |
BLACK |
| ST
1102A |
5.0 |
BLACK |
| ST 1102B |
9.5 |
BLACK |
| ST
1102C |
8.0 |
WHITE |
| ST 1102D |
14.0 |
BLACK |
| ST
1102E |
7.3 |
IVORY |
|
ST
1101
